波纹管直通接头-LKE00206
波纹管直通接头-LKE00206
产品材质： 采用TPE橡胶原料制成
工作温度： -40℃ ~ +100℃
防护等级： IP65
产品颜色： 黑色
注：其他规格、尺寸、颜色、特殊要求均可按需定制
|
|
订购代码 |
对应软管 |
适配软管 |
适配软管 |
外径 |
外径 |
长度 |
包装 |
|
|
|
Item No. |
Conduit item no |
Outer dia. |
Outer dia. |
Outer dia. |
Outer dia. |
length |
Std.Pkg. |
|
|
|
|
BG1×BG2 |
BG1 |
BG3 |
B1 |
B2 |
H |
PCS |
|
|
|
LKE-206-2×10.0 |
10.0×10.0 |
BG-07 |
BG-07 |
17.5 |
17.5 |
33.5 |
10PCS |
|
|
|
LKE-206-2×13.0 |
13.0×13.0 |
BG-10 |
BG-10 |
20 |
20 |
36.5 |
10PCS |
|
|
|
LKE-206-2×15.8 |
15.8×15.8 |
BG-12 |
BG-12 |
23 |
23 |
44.5 |
10PCS |
|
|
|
LKE-206-2×18.5 |
18.5×18.5 |
BG-15 |
BG-15 |
26.5 |
26.5 |
48 |
10PCS |
|
|
|
LKE-206-2×21.2 |
21.2×21.2 |
BG-17 |
BG-17 |
29.5 |
29.5 |
48 |
10PCS |
|
|
|
LKE-206-2×28.5 |
28.5×28.5 |
BG-23 |
BG-23 |
36.5 |
36.5 |
48 |
10PCS |
|
|
|
LKE-206-2×34.5 |
34.5×34.5 |
BG-29 |
BG-29 |
42.5 |
42.5 |
48 |
10PCS |
|
|
|
LKE-206-2×42.5 |
42.5×42.5 |
BG-36 |
BG-36 |
51 |
51 |
60 |
10PCS |
|
|
|
LKE-206-2×54.5 |
54.5×54.5 |
BG-48 |
BG-48 |
63 |
63 |
70 |
10PCS |
|
|
|
|
|
|
|
|
|
|
|
|
